The latest innovations from RUD.
RUD’s innovations consistently set new benchmarks in the market.
RUD is renowned for continually setting new standards. Technological innovation leadership has long been firmly embedded as a vision in our business strategy. Our stated aim: innovative product design, combined with the highest standards in manufacturing technology and quality management. Here, we set benchmarks that are recognised worldwide. Our highly qualified staff are passionate about meeting the needs of our current and future customers. After all, the driving force behind everything we do is to create added value through our solutions.
The right choice for every load: the RUD configurators.
Play it safe: the sling configurator guides you through a few simple steps to find the ideal sling configuration for your lifting application. With the attachment point configurator, you can quickly and easily find the right attachment point. Both tools offer an interactive 3D view as well as various settings and filter options to ensure you don’t miss a thing. Save valuable time too: you can conveniently request your configuration straight away.
The new ACP-TURNADO OCEANSTAR.
The first DNV-certified lifting point for subsea applications.
- Certified according to DNV-ST-0377 and DNV-ST-0378; fulfils ASME B30.26 and NORSOK R-002.
- No unexpected snagging of the load and no shock loads thanks to the innovative spring mechanism.
- All components have a zinc flake coating for maximum corrosion resistance – with a salt spray test resistance of 720 hours.
- All components have a reduced maximum hardness (≤ 38 HRC), making them highly resistant to hydrogen embrittlement.
- Nominal sizes: M8 – M30.
- WLL: 0.5 t – 8 t.
The RUD CCS-FASTLOX.
The first ever clickable clevis shackle for tool-free mounting. From RUD.
- Up to 80% faster mounting and dismounting.
- Easiest tool-free handling.
- Automatic securing of the shackle pin.
- Prevents incorrect bolt assembly.
- Can also replace hooks.
- Grades: 12 (ICE) and 10 (VIP).
- Nominal sizes from 4 to 16 (ICE) and 6 to 22 (VIP).
The RUD PIP-RAPIDO.
The first ever plug-in lifting point. From RUD.
- Quick, tool-free mounting.
- Up to 80% time savings compared to boltable lifting points.
- Ideal for through-holes (e. g. flanges) with hard-to-reach rear sides – and with undercut holes.
- Greater flexibility with tolerance ranges of 2 mm (diameter) and 10 mm (length) without compromising load-bearing capacity.
- Available in diameters ranging from 30 to 41 mm and lengths from 16 mm to 100 mm.
W-ABA Lifting point for welding.
Ready and indestructible – from all directions.
- Large WLL range 0.8 t – 31.5 t.
- Forged from a single piece, no rattling noise or shaking even with strong vibrations or shock loads, easy hinging of the lifting means possible.
- The weld arrangement (circular fillet weld) fulfils the requirements of DIN EN 1090, i.e. the endless weld seam prevents the formation of contact/crevice corrosion (thus suitable for outdoor constructions).
- Wear markings for easy determination of wear.
ACP-TURNADO.
The world’s first smart lifting point.
- The world’s first smart lifting point Large WLL range 0,7 t – 32,5 t.
- Innovative spring mechanism – prevents the lift bail from stopping with transverse load.
- Swivel joint in the lifting ring axis.
- Wear lenses for checking discard criteria.
- Integrated RFID transponder to make checks easier.
- Safety factors 4:1 and 5:1.
- Meets and exceeds the requirements of the American standard ASME B30.26.
