VIP-Special master links VSAK-2, 2-leg
VIP-Special master links with welded-in connectors.
- All special master links on this page are equipped with welded-in connectors that can be moved on all sides.
- This results in a non-mix-up connection to chain diameter and number of strands.
- The master link is supplemented with an identification tag (VKZA) with integrated chain test gauge.
- Due to the greater diameter of the inner width “B” of the VSAK reduces an unauthorised use (DGUV rule 109-017) and wear occurrence on the crane hook. This saves a costly intermediate suspension for oversized crane hooks.
Product variant (15)
VIP-Special master link VSAK-2-13 / 250
Article number: 7994080
| Attribute | Value |
|---|---|
| WLL | 9.500 kg |
| Weight | 14,73 kg |
| size A | 36 mm |
| size B | 250 mm |
| size C | 460 mm |
| pitch T | 634 mm |
Related downloads
Please use the contact form for further questions about our products and services.
-
VSAK-2-13/250 - DXF 2D CAD File
(ZIP, 52 KB)
-
VSAK-2-13/250 - IGES 3D CAD File
(ZIP, 567 KB)
-
VSAK-2-13/250 - STEP 3D CAD File
(ZIP, 233 KB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
VIP-Special master link VSAK-2-16 / 250
Article number: 7994081
| Attribute | Value |
|---|---|
| WLL | 14.000 kg |
| Weight | 20,57 kg |
| size A | 40 mm |
| size B | 250 mm |
| size C | 460 mm |
| pitch T | 671 mm |
Related downloads
Please use the contact form for further questions about our products and services.
-
VSAK-2-16/250 - DXF 2D CAD File
(ZIP, 50 KB)
-
VSAK-2-16/250 - IGES 3D CAD File
(ZIP, 603 KB)
-
VSAK-2-16/250 - STEP 3D CAD File
(ZIP, 250 KB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
VIP-Special master link VSAK-2-20 / 250
Article number: 7994083
| Attribute | Value |
|---|---|
| WLL | 22.400 kg |
| Weight | 32,56 kg |
| size A | 45 mm |
| size B | 250 mm |
| size C | 460 mm |
| pitch T | 724 mm |
Related downloads
Please use the contact form for further questions about our products and services.
-
VSAK-2-20/250 - DXF 2D CAD File
(ZIP, 57 KB)
-
VSAK-2-20/250 - IGES 3D CAD File
(ZIP, 701 KB)
-
VSAK-2-20/250 - STEP 3D CAD File
(ZIP, 289 KB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
VIP-Special master link VSAK-2-22 / 250
Article number: 7994084
| Attribute | Value |
|---|---|
| WLL | 28.000 kg |
| Weight | 39,5 kg |
| size A | 51 mm |
| size B | 250 mm |
| size C | 460 mm |
| pitch T | 754 mm |
Related downloads
Please use the contact form for further questions about our products and services.
-
VSAK-2-22/250 - DXF 2D CAD File
(ZIP, 52 KB)
-
VSAK-2-22/250 - IGES 3D CAD File
(ZIP, 636 KB)
-
VSAK-2-22/250 - STEP 3D CAD File
(ZIP, 264 KB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
VIP-Special master link VSAK-1-28/250 with VVS-28
Article number: 7914864
| Attribute | Value |
|---|---|
| WLL | 31.500 kg |
| Weight | 85,99 kg |
| size A | 71 mm |
| size B | 250 mm |
| size C | 460 mm |
| size D | 50 mm |
| size E | 100 mm |
| size F | 200 mm |
| pitch T | 850 mm |
Related downloads
Please use the contact form for further questions about our products and services.
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
-
(PDF, 4 MB)
