DOMINATOR

RUD flat connectors DOMINATOR for MINING can be used either vertically or horizontally in round link chain strands. Especially in plough chains acc. to DIN 22252 as well as horizontally as repair connectors in flat link chains acc. to DIN 22255 RUD connectors DOMINATOR are used.

Application areas of the RUD connector for mining DOMINATOR

• Heavy duty mining operations
• As a high-performance underground conveyor
• Single and multiple strand conveyors
• RUD flat connectors DOMINATOR can be used either vertically or horizontally in round link chain strands
• Especially in plough chains acc. to DIN 22252 as well as horizontally as repair connectors in flat link chains acc. to DIN 22255 RUD connectors DOMINATOR are used

Advantages of the connector for mining DOMINATOR

• Better mechanical and technical properties than required by DIN 22258
• Therefore, very high reliability and longer service life
• Sturdy, torsionally stiff design
• Increased operational safety
• Running horizontally and vertically over pocket wheels
• Excellent for use in plough systems
• 100 % crack free
• Perfectly corrosion protected
• Perfectly suited to your individual case of application
• Coupling dimensions correspond with chain link dimensions
• Easy hammer assembly
