R-Gabion

This type of Gabion has a very small risk of injuries (in opposite to commercial gabions) because there is no overhang of wire.

With our hoisting device it can also be used as “Transport Gabion”. Then you have the possibility to transport the basket after you have filled the stones into.

Technical Data

  • electrically spot welded wire mesh mats with ZnAl coated wire (Zn95%, Al5%) with 3,000 hours salt spray test according to DIN EN ISO 9227:2006-10 and a minimum coat thickness 350 g/mm² according to EN 10244-2
  • standard wire-Ø 4.5 and 5.0 mm - other wire sizes on request
  • spacer with wire Ø 5.0 mm
